#include <Svc/EventManager/EventManager.hpp>
Public Member Functions | |
| EventManager (const char *compName) | |
| constructor More... | |
| virtual | ~EventManager () |
| destructor More... | |
 Public Member Functions inherited from Svc::EventManagerComponentBase | |
| void | init (FwSizeType queueDepth, FwEnumStoreType instance=0) |
| Initialize EventManagerComponentBase object. More... | |
| Fw::InputCmdPort * | get_CmdDisp_InputPort (FwIndexType portNum) |
| Fw::InputLogPort * | get_LogRecv_InputPort (FwIndexType portNum) |
| Svc::InputPingPort * | get_pingIn_InputPort (FwIndexType portNum) |
| void | set_CmdReg_OutputPort (FwIndexType portNum, Fw::InputCmdRegPort *port) |
| Connect port to CmdReg[portNum]. More... | |
| void | set_CmdStatus_OutputPort (FwIndexType portNum, Fw::InputCmdResponsePort *port) |
| Connect port to CmdStatus[portNum]. More... | |
| void | set_Log_OutputPort (FwIndexType portNum, Fw::InputLogPort *port) |
| Connect port to Log[portNum]. More... | |
| void | set_Time_OutputPort (FwIndexType portNum, Fw::InputTimePort *port) |
| Connect port to Time[portNum]. More... | |
| void | set_FatalAnnounce_OutputPort (FwIndexType portNum, Svc::InputFatalEventPort *port) |
| Connect port to FatalAnnounce[portNum]. More... | |
| void | set_PktSend_OutputPort (FwIndexType portNum, Fw::InputComPort *port) |
| Connect port to PktSend[portNum]. More... | |
| void | set_pingOut_OutputPort (FwIndexType portNum, Svc::InputPingPort *port) |
| Connect port to pingOut[portNum]. More... | |
| void | regCommands () |
| Register commands with the Command Dispatcher. More... | |
| Public Member Functions inherited from Fw::ActiveComponentBase | |
| void | start (FwTaskPriorityType priority=Os::Task::TASK_PRIORITY_DEFAULT, FwSizeType stackSize=Os::Task::TASK_DEFAULT, FwSizeType cpuAffinity=Os::Task::TASK_DEFAULT, FwTaskIdType identifier=static_cast< FwTaskIdType >(Os::Task::TASK_DEFAULT)) |
| called by instantiator when task is to be started More... | |
| void | exit () |
| exit task in active component More... | |
| Os::Task::Status | join () |
| Join the thread. More... | |
| DEPRECATED (Os::Task::Status join(void **value_ptr), "Switch to .join()") | |
| Join to thread with discarded value_ptr. More... | |
| Public Member Functions inherited from Fw::QueuedComponentBase | |
| void | deinit () override |
| Allows de-initialization on teardown. More... | |
| Public Member Functions inherited from Fw::PassiveComponentBase | |
| void | setIdBase (const FwIdType) |
| Set the ID base. More... | |
| FwIdType | getIdBase () const |
Additional Inherited Members | |
| Public Types inherited from Fw::ActiveComponentBase | |
| enum | { ACTIVE_COMPONENT_EXIT } |
| Public Types inherited from Fw::QueuedComponentBase | |
| enum | MsgDispatchStatus { MSG_DISPATCH_OK, MSG_DISPATCH_EMPTY, MSG_DISPATCH_ERROR, MSG_DISPATCH_EXIT } |
| Protected Types inherited from Svc::EventManagerComponentBase | |
| enum | { NUM_CMDDISP_INPUT_PORTS = 1 } |
| Enumerations for numbers of special input ports. More... | |
| enum | { NUM_LOGRECV_INPUT_PORTS = 1, NUM_PINGIN_INPUT_PORTS = 1 } |
| Enumerations for numbers of typed input ports. More... | |
| enum | { NUM_CMDREG_OUTPUT_PORTS = 1, NUM_CMDSTATUS_OUTPUT_PORTS = 1, NUM_LOG_OUTPUT_PORTS = 1, NUM_LOGTEXT_OUTPUT_PORTS = 1, NUM_TIME_OUTPUT_PORTS = 1 } |
| Enumerations for numbers of special output ports. More... | |
| enum | { NUM_FATALANNOUNCE_OUTPUT_PORTS = 1, NUM_PKTSEND_OUTPUT_PORTS = 1, NUM_PINGOUT_OUTPUT_PORTS = 1 } |
| Enumerations for numbers of typed output ports. More... | |
| enum | { OPCODE_SET_EVENT_FILTER = 0x0, OPCODE_SET_ID_FILTER = 0x2, OPCODE_DUMP_FILTER_STATE = 0x3 } |
| Command opcodes. More... | |
| enum | { EVENTID_SEVERITY_FILTER_STATE = 0x0, EVENTID_ID_FILTER_ENABLED = 0x1, EVENTID_ID_FILTER_LIST_FULL = 0x2, EVENTID_ID_FILTER_REMOVED = 0x3, EVENTID_ID_FILTER_NOT_FOUND = 0x4 } |
| Event IDs. More... | |
| Protected Types inherited from Fw::ActiveComponentBase | |
| enum | Lifecycle { CREATED, DISPATCHING, FINALIZING, DONE } |
| Tracks the lifecycle of the component. More... | |
| Protected Member Functions inherited from Svc::EventManagerComponentBase | |
| EventManagerComponentBase (const char *compName="") | |
| Construct EventManagerComponentBase object. More... | |
| virtual | ~EventManagerComponentBase () |
| Destroy EventManagerComponentBase object. More... | |
| bool | isConnected_CmdReg_OutputPort (FwIndexType portNum) |
| bool | isConnected_CmdStatus_OutputPort (FwIndexType portNum) |
| bool | isConnected_Log_OutputPort (FwIndexType portNum) |
| bool | isConnected_Time_OutputPort (FwIndexType portNum) |
| bool | isConnected_FatalAnnounce_OutputPort (FwIndexType portNum) |
| bool | isConnected_PktSend_OutputPort (FwIndexType portNum) |
| bool | isConnected_pingOut_OutputPort (FwIndexType portNum) |
| void | LogRecv_handlerBase (FwIndexType portNum, FwEventIdType id, Fw::Time &timeTag, const Fw::LogSeverity &severity, Fw::LogBuffer &args) |
| Handler base-class function for input port LogRecv. More... | |
| void | pingIn_handlerBase (FwIndexType portNum, U32 key) |
| Handler base-class function for input port pingIn. More... | |
| virtual void | pingIn_preMsgHook (FwIndexType portNum, U32 key) |
| Pre-message hook for async input port pingIn. More... | |
| void | FatalAnnounce_out (FwIndexType portNum, FwEventIdType Id) |
| Invoke output port FatalAnnounce. More... | |
| void | PktSend_out (FwIndexType portNum, Fw::ComBuffer &data, U32 context) |
| Invoke output port PktSend. More... | |
| void | pingOut_out (FwIndexType portNum, U32 key) |
| Invoke output port pingOut. More... | |
| void | loqQueue_internalInterfaceInvoke (FwEventIdType id, const Fw::Time &timeTag, const Fw::LogSeverity &severity, const Fw::LogBuffer &args) |
| Internal interface base-class function for loqQueue. More... | |
| void | cmdResponse_out (FwOpcodeType opCode, U32 cmdSeq, Fw::CmdResponse response) |
| Emit command response. More... | |
| void | SET_EVENT_FILTER_cmdHandlerBase (FwOpcodeType opCode, U32 cmdSeq, Fw::CmdArgBuffer &args) |
| void | SET_ID_FILTER_cmdHandlerBase (FwOpcodeType opCode, U32 cmdSeq, Fw::CmdArgBuffer &args) |
| void | DUMP_FILTER_STATE_cmdHandlerBase (FwOpcodeType opCode, U32 cmdSeq, Fw::CmdArgBuffer &args) |
| virtual void | SET_ID_FILTER_preMsgHook (FwOpcodeType opCode, U32 cmdSeq) |
| Pre-message hook for command SET_ID_FILTER. More... | |
| virtual void | DUMP_FILTER_STATE_preMsgHook (FwOpcodeType opCode, U32 cmdSeq) |
| Pre-message hook for command DUMP_FILTER_STATE. More... | |
| void | log_ACTIVITY_LO_SEVERITY_FILTER_STATE (Svc::EventManager_FilterSeverity severity, bool enabled) const |
| void | log_ACTIVITY_HI_ID_FILTER_ENABLED (FwEventIdType ID) const |
| void | log_WARNING_LO_ID_FILTER_LIST_FULL (FwEventIdType ID) const |
| void | log_ACTIVITY_HI_ID_FILTER_REMOVED (FwEventIdType ID) const |
| void | log_WARNING_LO_ID_FILTER_NOT_FOUND (FwEventIdType ID) const |
| Fw::Time | getTime () const |
| Protected Member Functions inherited from Fw::ActiveComponentBase | |
| ActiveComponentBase (const char *name) | |
| Constructor. More... | |
| virtual | ~ActiveComponentBase () |
| Destructor. More... | |
| void | init (FwEnumStoreType instance) |
| initialization code More... | |
| virtual void | preamble () |
| A function that will be called before the event loop is entered. More... | |
| MsgDispatchStatus | dispatch () |
| The function that will dispatching messages. More... | |
| virtual void | finalizer () |
| A function that will be called after exiting the loop. More... | |
| Protected Member Functions inherited from Fw::QueuedComponentBase | |
| QueuedComponentBase (const char *name) | |
| Constructor. More... | |
| virtual | ~QueuedComponentBase () |
| Destructor. More... | |
| void | init (FwEnumStoreType instance) |
| initialization function More... | |
| Os::Queue::Status | createQueue (FwSizeType depth, FwSizeType msgSize) |
| MsgDispatchStatus | dispatchAvailableMessages () |
| dispatches all messages currently in the queue, returning status of the dispatch More... | |
| FwSizeType | getNumMsgsDropped () |
| return number of messages dropped More... | |
| void | incNumMsgDropped () |
| increment the number of messages dropped More... | |
| Protected Member Functions inherited from Fw::PassiveComponentBase | |
| PassiveComponentBase (const char *name) | |
| Named constructor. More... | |
| virtual | ~PassiveComponentBase () |
| Destructor. More... | |
| void | init (FwEnumStoreType instance) |
| Initialization function. More... | |
| FwEnumStoreType | getInstance () const |
| Protected Member Functions inherited from Fw::ObjBase | |
| ObjBase (const char *name) | |
| ObjBase constructor. More... | |
| virtual | ~ObjBase () |
| Destructor. More... | |
| void | init () |
| Object initializer. More... | |
| Static Protected Member Functions inherited from Svc::EventManagerComponentBase | |
| static constexpr FwIndexType | getNum_CmdDisp_InputPorts () |
| static constexpr FwIndexType | getNum_LogRecv_InputPorts () |
| static constexpr FwIndexType | getNum_pingIn_InputPorts () |
| static constexpr FwIndexType | getNum_CmdReg_OutputPorts () |
| static constexpr FwIndexType | getNum_CmdStatus_OutputPorts () |
| static constexpr FwIndexType | getNum_Log_OutputPorts () |
| static constexpr FwIndexType | getNum_Time_OutputPorts () |
| static constexpr FwIndexType | getNum_FatalAnnounce_OutputPorts () |
| static constexpr FwIndexType | getNum_PktSend_OutputPorts () |
| static constexpr FwIndexType | getNum_pingOut_OutputPorts () |
| Protected Attributes inherited from Fw::ActiveComponentBase | |
| Os::Task | m_task |
| task object for active component More... | |
| Protected Attributes inherited from Fw::QueuedComponentBase | |
| Os::Queue | m_queue |
| queue object for active component More... | |
Definition at line 17 of file EventManager.hpp.
| Svc::EventManager::EventManager | ( | const char * | compName | ) |
constructor
Definition at line 21 of file EventManager.cpp.
|
virtual |
destructor
Definition at line 39 of file EventManager.cpp.
